Outside many hotels, we will see a large smoke exhaust pipe to exhaust useless exhaust gas, but do you know that, Shenyang ventilation pipeline How is the installation position of?
The ventilation and smoke exhaust pipe facilities of high-rise buildings shall be divided into mechanical smoke exhaust facilities and natural smoke exhaust facilities that can open external windows.
The mechanical smoke exhaust system of the room is set according to the smoke control zone.
(1) The following parts of Class I high-rise buildings and Class II high-rise buildings with a building height of more than 32m shall be equipped with smoke exhaust facilities:
1) Internal walkways with a length of more than 20m;
2) Rooms with an area of more than 100m2 and frequent people staying or more combustibles;
3) Atrium of high-rise buildings and basements where people often stay or there are many combustibles.
(2) Fire and smoke prevention measures shall be taken for ventilation and air conditioning systems.
(3) The following parts of Class I high-rise buildings and Class II high-rise buildings with a building height of more than 32m shall be equipped with mechanical smoke exhaust facilities:
The inner walkway without direct natural ventilation and with a length of more than 20m or with a length of more than 60m despite direct natural ventilation;
Rooms without windows on the ground or with fixed windows with an area of more than 100m2 and frequent people staying or more combustibles;
Atrium without natural smoke exhaust conditions or with a clearance height of more than 12m;
In addition to the rooms that use windows such as window wells for natural smoke exhaust, the total area of each room exceeds 200m2 or the area of one room exceeds 50m2, and there are often people staying or there are many combustibles in the basement.
The ventilation and smoke exhaust pipe facilities set in high-rise buildings shall meet the following requirements:
(1) The smoke outlet shall be set on the ceiling or on the wall near the ceiling, and the horizontal distance from the adjacent edge of the nearby emergency exit along the aisle direction shall not be less than 1.50m. The distance from the smoke outlet on the ceiling to combustible components or combustibles shall not be less than 1.00 m.
The smoke outlet shall be closed at ordinary times, and shall be equipped with manual and automatic opening devices.
(2) The horizontal distance between the smoke outlet in the smoke control zone and the remote point shall not exceed 30m.
The smoke exhaust branch pipe shall be equipped with smoke exhaust that can be automatically closed when the smoke temperature exceeds 280 ℃ Fire damper 。
(3) The smoke exhaust fan can be centrifugal fan or smoke exhaust fan Axial flow fan The entrance of the machine room shall be equipped with smoke fire damper which can automatically close when the flue gas temperature exceeds 280 ℃. The smoke exhaust fan shall be able to work continuously for 30min at 280 ℃.
(4) In the mechanical smoke exhaust system, when any smoke outlet or smoke exhaust valve is opened, the smoke exhaust fan shall be able to start automatically.
